Warn 478022 M15 Series 24V Heavyweight Winch - 15,000 lbs. Capacity -Each Fits select: 1999-2013 CHEVROLET SILVERADO, 1999-2003 FORD F150
Product details
| Management number | 251641610 | Release Date | 2026/09/26 | List Price | US$1,332.40 | Model Number | 251641610 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
When you own a big truck, you need the pulling power to get that truck out of tough situations and the M15000 does just that. The M15000 features high-strength carrier plates to handle the stresses of pulling a 15,000 lb. load, a smooth and durable 3-stage planetary geartrain, and 90' of 7/16 wire rope equipped with a large hook with clasp. The control pack is designed for plenty of clearance and ease of access.M15000 Specs/Part Numbers Part Numbers: PN 478022 CE (24V DC);Rated Line Pull: 15000 lbs. (6804 kgs.) single-line; Motor: 24V 2.5 hp Series WoundTM; Remote Control: Remote, 12' (3.7m) lead; Geartrain: 3-Stage Planetary; Gear Ratio: 315:1;Lubrication: Molylube #1 or Aeroshell #17;Clutch (free spooling): Rotating Ring Gear; Brake: Automatic Direct Drive Cone; Drum Diameter/Length: 3.5/8.2 (9cm/21cm);Weight: 136lbs. (62kgs.);Wire Rope: 90', 7/16 diameter (27m, 11mm diam.)Fairlead: Roller; Recommended Battery: 650 CCA minimum for winching; Battery Leads: 2 gauge, 72 (1.83m);Finish: Argent Gray Powder Coat[*]Nuts/Bolts: PN 6194624v DC Winch
- WARN heavy weight series winch is for the heavy-duty jobs, designed to handle heavier winch loads
- Ideal for heavier trucks and SUVs, great for off-roading and vehicle recovery
- 90 feet of steel rope with 15,000 lbs of pulling power
- One of the most powerful winches on the market, in a 24 volt configuration
| Pull capacity | 15000 lb |
|---|---|
| Brand | Warn |
| Towing winch type | Planetary Gear |
| Power type | Battery |
| Volts | 24 V |
| Cable length | 90 ft |
| Winch cable material | Steel |
| Accessories | Wired Remote |
| Features | Remote Controlled |
| Vehicle fitment type | Specific |
| Vehicle type | Truck |
| Series | M15 Series |
| Model | 478022 |
| Vehicle make | Chevrolet, Ford |
| Vehicle model | SILVERADO |
| Horsepower | 4.6 HP |
| Has written warranty | No |
| Material | Steel |
| Assembled product dimensions (l x w x h) | 28.00 x 13.00 x 10.00 Inches |
| Assembled product weight | 135 lb |
| Compatible cars | 1999-2013 CHEVROLET SILVERADO, 1999-2003 FORD F150 |
| Finish | chip-resistant powder-coated |
